°Catalytic Instruments

Ready to elevate your aerosol research?

Contact us today to schedule a consultation or to learn more about our devices and services.

The importance of CCS

The °Catalytic Stripper (CS) is a device used in particle number measurement systems to eliminate volatile and semi-volatile particles, ensuring only solid particles are counted. It is required in the PMP protocol (EURO 7, EURO VII) for accurate particle emissions testing to reliably remove all volatile components of the aerosol.  The ºCatalytic Stripper is now required in order to meet these measurement conditions, as the previous technology of a simple evaporation tube is not capable to reliably remove all volatile components from the aerosol, resulting in measurement artefacts and incorrect data and interpretation.

34
35

Other models

°Catalytic Stripper Models Comparison
SpecificationCCS004CS015CS03CS06CS08CS10CS15
Inlet Flowrate0.4 L/min1.5 L/min0.3 L/min0.6 L/min8 L/min10 L/min15 L/min
Oxidation Efficiency>99% of propane
Solid Particle Lossat 50 nm and 1 mg/m³ mass.
Operating Gas Temperature350°C
Outlet TemperatureAmbient + 25°C
